BRAKE SHOE GROVED KTM EBC 814G

This grooved motorcycle brake shoe set from EBC Brakes provides consistent braking performance and control for off-road riding. The Water Grooved design and high-pressure die-cast aluminium platform with 100% asbestos-free bonded lining balance bite, modulation and durability under heat. Supplied as a complete shoe set with original equipment style springs, it is suitable for selected KTM off-road models in front or rear drum applications and is produced as an OE-quality replacement part where applicable.

Features

• Multiple angled liner grooves help disperse water, dirt and dust from the braking surface


• Intended to maintain consistent brake response and reduce drum wear in wet or muddy conditions


• Designed for drum brake use on off-road motorcycles and ATV/UTV applications

Specifications

• Product type: Brake shoe set


• Product range/series: Water Grooved


• Position: Front or rear (application dependent)


• Compound / material: 100% asbestos-free bonded brake lining


• Construction / design: High-pressure die-cast aluminium shoe platforms with grooved linings, radius grinding, edge trimming and lead-in/lead-out chamfers

Dimensions

• Disc/rotor diameter: 130 mm (drum)


• Weight: 0.25 kg

Cross Reference Numbers

• 814G

Vehicle Fitment

KTM (Rear Left)

• 80 MX (1986-1992)


• GSXC|GS 300 (1985)


• MX|MXC 300 (1985)

KTM (Rear Right)

• GSXC|GS 125 (1985)


• MX 125 (1984)


• MX|MXC 125 (1985)


• GSXC|GS 250 (1985)


• MX|MXC 250 (1985)


• MX|MXC|GS 250 (1984)


• MX|MXC|XC-GS 500 (1985)
