PISTON KIT 89-95 RM250 69.00, WOSSNER 8022D200 SUZUKI MX

The Wossner 8022D100 piston with a 69mm bore (68.94mm actual size) is engineered for high durability and strength, fitting Suzuki RM250 (1989-1995) and RMX250 (1993-1995) models. Forged in Germany, it is designed to maximise heat transfer from the combustion chamber to the cylinder walls. The elliptical piston shape promotes even distribution of thrust loads under heat expansion, reducing localised stresses and preventing piston collapse.

Features

•


  Forged construction for enhanced strength and resilience





•


  Optimised for efficient heat transfer to cylinder walls





•


  Elliptical design for uniform load distribution under thermal expansion





•


  Manufactured in Germany




Specifications

•


  Bore: 69mm (actual size 68.94mm)





•


  Part Number: 56-W642_200.WO





•


  Lock Part Number: CW18





•


  Pin Part Number: WP033





•


  Ring Set Part Number: RSB6700 x 2





•


  Displacement: 246 cm³





•


  Stroke: 70.80mm





•


  Clearance: 0.06mm





•


  Wossner Compression Ratio: 2-stroke





•


  OEM Compression Ratio: 2-stroke





•


  Compression Height: 37.00mm




Cross-Reference OEM Part Numbers

•


  Piston: 12110-28C11-0F0, 12110-29E20-0F0





•


  Ring, Piston: 12141-41600, 12141-41620





•


  Pin, Piston: 12151-28C00, 12151-37F00





•


  Circlip: 09381-18002




Vehicle Fitments

•


  1989-1995 Suzuki RM250





•


  1993-1995 Suzuki RMX250
