PISTON KIT 89-95 RM250 68.00, WOSSNER 8022D100 SUZUKI MX

Piston 68mm Bore 67.94 Wossner 8022D100 (+1.00)

Suzuki

RM250 1989-1995,

RMX250 1993-1995,

• Wossner forged pistons are superior in strength and design.


• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.


• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.


• Made in Germany.

Part No. 56-W642_100.WO (oro2u.com)

Lock P/N CW18

Pin P/N WP033

Ring Set P/N RSB6800 x 2

Display (cm3) 246

Hub stroke (mm) 70.80

Clearance (mm) 0.06

Wossner compression Ratio: 2 stroke

OEM Compression ratio: 2 stroke

Dome volume (cm3)

Compression height (mm) 37.00

Theorectical weight (G)

Cross reference numbers ONLY.

PISTON 12110-28C11-0F0, 12110-29E20-0F0 , RING, PISTON 12141-41600, 12141-41620, PIN, PISTON 12151-28C00, 12151-37F00 , CIRCLIP 09381-18002,
