PISTON KIT 1988 RM125 56.00, WOSSNER 8138D200 SUZUKI MX
PISTON KIT 1988 RM125 56.00, WOSSNER 8138D200 SUZUKI MX
The Wossner 8138D200 piston kit is engineered for the 1988 Suzuki RM125 and features a 56.00 mm bore for +2.00 mm oversize applications. Made in Germany with forged construction, this piston provides excellent durability and efficient heat transfer. Its elliptical design ensures a consistent bearing surface during thermal expansion, effectively distributing thrust loads and reducing the risk of piston collapse. This kit includes all essential components for reliable engine rebuilds.
Features
-
Forged piston offers enhanced strength and durability
-
Optimised for heat dissipation from the combustion chamber
-
Elliptical design ensures even load distribution during expansion
-
Helps prevent piston failure under thermal stress
-
Manufactured in Germany for high precision and quality
Specifications
-
Bore Size: 56.00 mm
-
Actual Bore Diameter: 55.94 mm
-
Stroke: 54.00 mm
-
Display Displacement: 123 cm³
-
Clearance: 0.06 mm
-
Compression Ratio (Wossner and OEM): 2-stroke
-
Compression Height: 29.50 mm
Cross-Reference Wossner Part Numbers
-
Piston Kit: 8138D200
-
Lock: CW15
-
Pin: WP032
-
Ring Set: RSB5600
-
Rod: P2015
-
Part No.: 56-W568+200.WO
Vehicle Fitments
-
Suzuki RM125 (1988)
