GASKET TOP SET TRX250 TRX300

K&S 70-1041T is a top end gasket kit for Honda ATC, TRX and TRX-FW applications. It is used during a top end rebuild to replace the required gaskets, washers and O-rings.

Features

• Provides the sealing components required for a top end rebuild

Kit Contents

• 1 x Cylinder head gasket


• 1 x Cylinder base gasket


• 2 x Tappet cover gaskets


• 1 x Cam chain tensioner holder gasket


• 2 x Valve stem seals


• 1 x Exhaust pipe gasket


• 2 x Valve guide O-rings, 10 x 1.6 mm


• 1 x Cylinder head O-ring, 33.7 x 2.4 mm


• 2 x Cylinder head O-rings, 3.7 x 2.6 mm, 1985 models only


• 2 x Camshaft O-rings, 77 x 2.5 mm


• 1 x Cylinder O-ring, 78.3 x 2 mm


• 1 x Tensioner gasket, 6 x 15 x 5 mm, TRX 300 and TRX 300FW 1988-1990 only


• 1 x Tensioner sealing washer, 6 x 14 x 1 mm, TRX 300 and TRX 300FW 1991-2000 only


• 3 x Cylinder head sealing washers, 7 mm


• 3 x Cylinder head sealing washers, 8 mm


• 1 x Cylinder head sealing washer, 6 x 13 x 1.5 mm


• 1 x Cylinder head sealing washer, 6 mm, 1985 models only

Cross-Reference OEM Part Numbers

•


  K&S 70-1041T




Vehicle Fitments

• Honda ATC 250ES 1985-1986


• Honda ATC 250SX 1985-1986


• Honda TRX 250 1985-1987


• Honda TRX 300 1988-2000


• Honda TRX 300FW 1988-2000
