PISTON KIT 04-07 KTM300 72.00, WOSSNER 8219DA FORGED 55430007000

This 72mm bore Wossner piston kit (part number 8219DA) is a standard size forged piston specifically engineered for KTM 300cc two-stroke engines produced between 2004 and 2007. It is designed for optimal combustion efficiency, durability, and heat transfer, making it suitable for high-performance off-road applications.

Features

•


  Forged piston construction for increased strength and durability





•


  Engineered to optimise combustion chamber heat transfer





•


  Elliptical design enhances bearing surface and distributes thrust loads evenly





•


  Helps prevent piston collapse under heat expansion





•


  Made in Germany




Specifications

•


  Bore diameter: 72.00 mm





•


  Display displacement: 293 cm³





•


  Stroke: 72.00 mm





•


  Clearance: 0.06 mm





•


  Compression ratio: 2-stroke specification (Wossner and OEM)





•


  Compression height: 38.00 mm




Cross-Reference OEM Part Numbers

•


  55430007000





•


  09104880





•


  858M07200




Included Components

•


  Piston kit part number: 56-W858.A.WO





•


  Rings (2x): RSB7200





•


  Circlip: CW18





•


  Wrist pin: WP033





•


  Gasket: D2024-EST





•


  Connecting rod: P2023




Vehicle Fitments

•


  KTM EXC 300 2004–2007





•


  KTM MXC 300 2004–2007





•


  KTM XC 300 2004–2007





•


  KTM XC-W 300 2004–2007
