BRAKE SHOES SUZUKI S621

This brake shoe set from EBC Brakes provides consistent braking performance and control for road use. The plain motorcycle replacement design and high-pressure die-cast aluminium shoe platform construction with bonded brake linings balance bite, modulation and durability under heat. Supplied as a complete brake shoe set with OE-style brake shoe springs, it is suitable for motorcycle drum brake systems in applications where specified.

Features

• Radius ground to match the drum for stable contact and predictable engagement


• Lining ends chamfered to promote smooth initial bite


• Supplied with OE-style brake shoe springs for correct return and fit

Specifications

• Product type: Brake shoe set


• Product range/series: Plain motorcycle replacement brake shoes


• Compound / material: Bonded brake linings


• Construction / design: High-pressure die-cast aluminium shoe platforms with bonded linings


• Direction of rotation: Not directional

Dimensions

• Pad/shoe dimensions (L × H × T): 140 mm (diameter)


• Weight: 0.35 kg

Cross Reference Numbers

•


  EBC: S620




Vehicle Fitment

SUZUKI (Rear Left)

• RM 250 (1979-1980)


• RM 400 (1979-1980)
