TIE ROD END KIT KAWASAKI SUZUKI YAMAHA 51-1028

The Factory Image Racing Tie Rod End Kit is a replacement steering linkage kit for selected ATV and quad applications. It is used to replace loose or worn tie-rod ends and helps restore correct steering connection between the tie rod and steering assembly. The kit includes the tie rod ends required for one tie rod, with one left-hand thread end and one right-hand thread end.

Features

• Replaces loose or worn tie-rod ends


• Includes both inner and outer ends for one tie rod


• Suitable for ATV and quad steering applications


• Designed to work with original equipment tie rods


• Sold as a pair for one-side tie rod replacement

Specifications

• Kit type: Tie rod end kit


• Quantity per kit: 2 tie rod ends


• Thread configuration: 1 left-hand thread and 1 right-hand thread

Cross-Reference OEM Part Numbers

• All Balls: 51-1028


• 251-1028


• Part number: 17-7027


• Part number: 17-7027.AB

Vehicle Fitments

Arctic Cat

• 150 Utility (2009-2013)


• 250 2x4 (2006-2009)


• 250 DVX (2006-2008)


• 300 2x4 / Utility (2010-2016)


• 300 DVX (2009-2015)


• 400 DVX (2004-2008)

Can-Am

• DS 450 (2010-2015)


• DS 450 EFI XXC (2009-2012)


• DS 450 STD/X (2008-2009)

CF-Moto

• X5 Terralander 500 (2011-2014)


• CF500 (2007-2016)


• X6 Terralander 625 EFI (2011-2014)


• X8 Terralander 800 (2012-2014)


• CF800 (2015-2016)

Honda

• TRX250R FourTrax (1986-1989)

Kawasaki

• KVF300 Brute Force (2012-2018)


• KFX400 / KSF400A KFX (2004-2006)


• KFX450R / KSF450B KFX450R (2008-2014)

Suzuki

• LT-F250 Ozark (2004-2014)


• LT-Z250 Quad Sport Z (2004-2009)


• LT-A400F Eiger 4WD (2005-2007)


• LT-F400 Eiger 2WD (2007)


• LT-F400F Eiger 4WD (2005-2007)


• LT-Z400 Quad Sport Z (2004-2014)


• LT-A500F Vinson (2004-2007)


• LT-A500X (2009-2010)


• LT-A500XP Power Steering (2011-2017)


• LT-F500F Vinson (2004-2007)


• LT-R450 Quad Racer (2006-2011)


• LTA-750 X King Quad (2011-2012, 2015)


• LTA-750 XP King Quad Power Steering (2011-2015)

Yamaha

• YFS200 Blaster (1988-2006)


• YFB250FW Timberwolf 4x4 (1994-2000)


• YFM350 Raptor (2004-2013)


• YFM350 Warrior (1987-2004)


• YFM350FGW Grizzly 4WD (2012-2014)


• YFM350FW Big Bear 4x4 (1987-1999)


• YFM350FX Wolverine 4x4 (1995-2005)


• YFM350U Big Bear 2x4 (1996-1999)


• YFZ350 Banshee (1987-2009)


• YFM400 Kodiak 2WD (2000-2001)


• YFM400 Kodiak 4WD (1993-2002)


• YFM450 Grizzly EPS (2013-2014)


• YFM450 Grizzly IRS (2013-2014)


• YFZ450 (2004-2013)


• YFZ450R (2009-2018)


• YFZ450X (2010-2011)


• YFM550 Grizzly (2009-2014)


• YFM550 Grizzly EPS (2009-2014)


• YFM600 Grizzly (1998-2001)


• YFM660 Grizzly (2002-2008)


• YFM660R Raptor (2001-2005)


• YFM700 Grizzly (2007-2013)


• YFM700 Grizzly EPS (2008-2013)


• YFM700R Raptor (2006-2018)
