PISTON KIT SACHS 125/7 55.25, WOSSNER 8287D150 PIN 16mm
PISTON KIT SACHS 125/7 55.25, WOSSNER 8287D150 PIN 16mm
This Wossner forged piston kit with a 55.25mm bore is an oversized (+1.50mm) replacement for the Sachs 125/7 engine. Manufactured in Germany, it delivers excellent strength and heat transfer performance. The elliptical piston design ensures even pressure distribution during thermal expansion, reducing localised stress and enhancing durability in two-stroke engine applications.
Features
-
Forged construction for superior strength and longevity
-
Engineered for efficient combustion chamber heat dissipation
-
Elliptical profile maintains consistent bearing surface under thermal load
-
Even distribution of thrust loads minimises piston stress and wear
-
Manufactured in Germany
Specifications
-
Bore: 55.25mm (+1.50mm Oversize)
-
Actual bore: 55.19mm
-
Display volume: 122 cm³
-
Stroke: 54.00mm
-
Clearance: 0.06mm
-
Wossner compression ratio: 2-stroke
-
OEM compression ratio: 2-stroke
-
Compression height: 38.00mm
Cross-Reference OEM Part Numbers
-
56-W9844.150
-
8287D150
-
Clip Part Number: CW16
-
Pin Part Number: WP136
-
Ring Set Part Number: RSB5525 (x2)
Vehicle Fitments
-
Sachs 125/7
