PISTON KIT 98-02 KTM380 79.00, WOSSNER 8223D100 FORGED

This Wossner piston kit with a 79.00mm bore (+1.00mm oversize, actual size 78.94mm) is designed for KTM 380 models—EGS, EXC, and SX—from 1998 to 2002. Forged in Germany, it is built for strength, consistent thermal transfer, and long-term reliability in high-performance two-stroke engines.

Features

•


  High-strength forged piston construction for maximum durability





•


  Designed to optimise heat dissipation from the combustion chamber to the cylinder wall





•


  Elliptical design provides a uniform bearing surface, reducing localised pressure and preventing piston collapse





•


  Manufactured in Germany with precision engineering for reliable performance




Specifications

•


  Bore size: 79.00 mm





•


  Actual piston size: 78.94 mm





•


  Display (cm³): 368





•


  Stroke (mm): 77.00





•


  Clearance (mm): 0.06





•


  Compression ratio: 2-stroke (Wossner and OEM)





•


  Compression height (mm): 27.00




Vehicle Fitments

•


  1998–2002 KTM EGS 380





•


  1998–2002 KTM EXC 380





•


  1998–2002 KTM SX 380




Included Components

•


  Piston: Wossner PN# 8223D100





•


  Lock: PN# CW18





•


  Pin: PN# WP039





•


  Ring Set: PN# RSC7900
