PISTON KIT 15-16 CRF450R 96mm, WOSSNER 8919DA, 13110-MEN-A90

This Wossner forged piston kit is a standard-size replacement specifically designed for Honda CRF450R models from 2015 onward. Built for high-performance four-stroke engines, it combines precise engineering and durable construction to support competitive and off-road use.

Features

•


  Forged construction for high durability and strength under performance conditions





•


  Elliptical design ensures a uniform bearing surface during heat expansion





•


  Efficient heat transfer from combustion chamber to cylinder walls





•


  Prevents piston collapse through even thrust load distribution





•


  Manufactured in Germany




Specifications

•


  Bore Size: 96.00mm





•


  Actual Piston Size: 95.96mm





•


  Display Displacement: 449 cm³





•


  Stroke: 62.10mm





•


  Piston Clearance: 0.04mm





•


  Wossner Compression Ratio: OEM





•


  OEM Compression Ratio: 12.50:1





•


  Dome Volume: -2.24 cm³





•


  Compression Height: 20.60mm





•


  Theoretical Weight: 241.00g





•


  Circlip Part Number: CW19





•


  Pin Part Number: WP028





•


  Ring Set Part Number: 960ADS-2




Cross-Reference OEM Part Numbers

•


  Part No: 56-W927.A.WO





•


  Cross Reference: 13110-MEN-A90, 40089M09600




Vehicle Fitments

•


  Honda CRF450R (2015– )
