PILOT JET SLOW 40 MIKUNI M4 EACH

Mikuni M4 size 40 pilot/slow jet for compatible carburettors, designed to meter fuel through the pilot circuit during starting, idle and low-throttle operation. It is suitable as a direct replacement jet where a Mikuni M4/VM28/1001-type pilot jet in size 40 is specified.

Features

• Controls fuel delivery through the carburettor pilot circuit


• Suitable for starting, idle and low-throttle fuelling


• Direct replacement for compatible Mikuni carburettor applications


• Suitable for off-road and motorcycle carburettor applications

Specifications

• Jet size: 40


• Type: Pilot / slow jet


• M4 pattern


• Length: 9.5 mm


• Head diameter: 4 mm

Cross-Reference OEM Part Numbers

• VM28/1001


• VM28-1001

Vehicle Fitments

Kawasaki

- KX65

Suzuki

- RM65

Yamaha

•


  RX50 Special (1983-1984)





•


  YSR50 (1987-1992)





•


  RD60 (1973-1974)





•


  YZ80 (1975-2001)





•


  DT125 (1974-1981)





•


  DT175 (1974-1981)





•


  MX175 (1979-1981)





•


  YFS200 Blaster (1988-2006)





•


  RZ350 (1984-1985)





•


  YFZ350 Banshee (1987-2006)
