LEFT RACK & PINION REBUILD KIT, ALLBALLS 51-1047-L, Can-Am

Rack and Pinion End Kit - Left Hand Side - 0430-0740 ALLBALLS 51-1047-L

UTV steering rack rod ends save customers hundreds of dollars on the cost of a complete steering rack assembly. The inner rod assemblies have increased shaft diameters for improved strength. Each kit includes heavy-duty inner and outer rod ends with a replacement boot, clamps, and any required lock washers. Outer tie rod ends are also available individually.

Included Items:

• (1) 12mm-1.25 right-hand thread tie rod end


• (1) 12mm-1.25 hex nut


• (1) 10mm-1.25 x 90mm hex head bolt


• (1) 10mm-1.25 nyloc nut


• (2) 10mm ID x 25mm OD flat washers


• (1) 12mm ID x 30mm OD flat washer


• (1) 14mm-1.50/12mm-1.25 right-hand thread rack end


• (1) Black rubber boot


• (2) 7 1/2 in. black plastic cable ties

Tie Rod End Kit Left (Inner and Outer)

Contains both the tie rod end and shaft that connects to the steering rack, as well as the outer tie rod end. Kit also includes a boot and required hardware for the left (driver) side.

Fitment List

Can-Am

• 2012 Can-Am Commander 1000 STD


• 2012 Can-Am Commander 1000 XT/LTD/DPS


• 2012 Can-Am Commander 800 STD


• 2012 Can-Am Commander 800 XT

Left Rack & Pinion Rebuild Kit

ALLBALLS 51-1047-L

Includes heavy-duty tie rod outer end and boot.
